Heritage Model 8021 Parts  #8021

Heritage Model 8021 Parts


Item#: 8021

Price: $0.00


Order Now

Item description (Part Number)

QTY: 1- Stone Right side 6 11/16in x 9 1/2in (1421-56) +$135.26

QTY: 2- Stone Rear Corner 8in x 9 1/2in (1201-25) +$142.88

QTY: 3- Stone Rear Center 8in x 9 1/2in (1201-26) +$142.88

QTY: 4- Stone Left Side Bottom 4 5/32in x 6 11/16in (1141-240) +$33.60

QTY: 5- Stone Left Side Top 2 7/8in x 6 11/16in (1141-242) +$51.03

QTY: 6- Stone Front Corner 2 19/32in x 9 1/2in (1141-253) +$48.36

QTY: 7- Stone Front Top 2 3/4in x 9 1/2in (1141-251) +$73.01

QTY: 8- Stone Front Bottom 3 3/4in x 9 1/2in (1141-252) +$73.01

QTY: 9- Bottom Casting (2010-225) +$595.73

QTY: 10- Top Casting (2010-290) +$579.89

QTY: 11- Stone Top Left & Right 8-1/16in x 15-3/4in (1141-243) +$174.51

QTY: 12- Stone Top Center 1/32 (1141-261) +$145.43

QTY: 13- Foot [Short] (2010-210) +$103.50

QTY: 13a- Foot [Long] (2010-910) +$216.44

QTY: 14- Corner Post [Leg] (2010-230) +$252.01

QTY: 15- Flue Collar (2010-285) +$164.35

QTY: 16- Top Radiation Shield (5570-150) +$79.36

QTY: 17- Flue Collar Frame (2010-280) +$269.80

QTY: 18- Primary Air Control Shutter (5021-025) +$26.02

QTY: 20/75 Ash Pan Door and Frame, matched set (2010-216) +$476.36

QTY: 21- Ash Pan Door Latch Assembly (90-73216) +$177.05

QTY: 21a- Set Screw (4500-2976) +$10.65

QTY: 21a- Chrome Handle Crank (5021-012) +$76.82

QTY: 21a- Spring (5240-135) +$28.69

QTY: 21a- Ash Pan Door Latch (5021-053) +$99.69

QTY: 23- Primary Air Handle (5021-030) +$35.18

QTY: 25- Wooden Handle Assembly [includes] (90-71100) +$32.55

QTY: 25a- Wood Handle (3900-177) +$47.03

QTY: 26- Secondary Air Riser (5021-040) +$99.69

QTY: 27- Secondary Air Plenum -Left Side (2010-242) +$275.39

QTY: 28- Secondary Air Plenum -Right Side (2010-240) +$225.33

QTY: 29- Secondary Air Pipe #1 [Rear] (5021-041) +$81.90

QTY: 30- Secondary Air Pipe #2 [Center] (5021-042) +$81.90

QTY: 31- Secondary Air Pipe #3 [Front] (5021-043) +$81.90

QTY: 32- Baffle Support (5021-065) +$142.88

QTY: 33- Ceramic Baffle Kit [Includes Ceramic Baffle Board, Bracket, Wire] ~Old part #90-76210~ (90-76230) +$169.43

QTY: 33b- Bracket: Baffle, SS (5021-066) +$41.70

QTY: 33c- Wire: 16 guage, SS 3 ft. (7000-090) +$10.65

QTY: 34- Firebox Refractory Stones (1-0000-101) +$73.01

QTY: 35- Ash Grate -Top (2010-228) +$157.99

QTY: 37- Cast Trim -Right Side (2010-275) +$103.50

QTY: 38- Cast Side Loading Door (2010-250) +$216.44

QTY: 39- Side Door Retainer Plate (2010-252) +$208.81

QTY: 40- Side Door Stone Inlay 8 3/8 (1141-241) +$163.08

QTY: 41- Cast Side Door Outer Frame (2010-255) +$252.01

QTY: 42- Cast Side Door Inner Frame (2010-257) +$208.81

QTY: 43- Side Door Outer Frame Plate (5021-055) +$32.69

QTY: 44- Front Door Latch Assembly [includes] (90-73212) +$108.58

QTY: 44a- Set Screw (4500-2976) +$10.65

QTY: 44b- Spacer (4700-0790) +$10.65

QTY: 44c- Chrome Handle Crank (5010-081) +$47.03

QTY: 44d- Spring (5240-138) +$23.35

QTY: 44e- Front Door Latch (5021-022) +$48.36

QTY: 44f- Washer (5021-032) +$10.65

QTY: 49- Wooden Handle Assembly [includes Wood Handle, Screw, Washer] (90-71100) +$32.55

QTY: 49a- Wood Handle (3900-177) +$47.03

QTY: 49b- Screw: Machine, 1/4-20x3-1/4 (4500-1680) +$10.65

QTY: 49c- Washer: Lock, 1/4 (4600-0400) +$10.65

QTY: 50- Primary Air Plenum (2010-245) +$393.54

QTY: 51- Front Door Outer Frame [This part bolts onto the front of the stove. It has the Door Catch built-in. On older stoves it is recommended to get a front door support kit, 90-85210-10. This kit, 90-85210-10, would include a new door and frame that is made together.] ~OLD PART #2010-265~ (90-85215) +$298.54

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~MATTE BLACK~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-10) +$734.05

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~BROWN ENAMEL~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-20) +$904.01

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~ALMOND ENAMEL~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-30) +$904.01

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~BLACK ENAMEL~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-50) +$904.01

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~BLUE BLACK~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-59) +$904.01

QTY: FRONT DOOR SUPPORT REPLACEMENT KIT ~SEAFOAM~ [Includes- Inner Door Frame, Outer Door Frame, Glass, Door & Window Gasket, Door Latch] (90-85210-61) +$904.01

QTY: 51A- Door Catch [Striker] - Old Style (Call for part #) +$Call to order

QTY: 51B- Door Catch [Striker] - Redesigned (Call for part #) +$Call to order

QTY: 51C- Left Striker - Front Door Frame (5021-056) +$51.03

QTY: 51D- Screw Front Door Frame Screw [4 required per unit, each sold separately] (4500-1910) +$10.65

QTY: 52- Front Door (2010-270) +$241.85

QTY: 52A- Door Hinge Pins [2 required per unit, each sold separately](4400-0300) +$10.65

QTY: 53- Front Door Glass Kit [Included in this kit Glass, Glass Gasket, Glass Gasket Clips, Glass Clips](90-58215) +$265.65

QTY: 53A- Glass Gasket (3110-056-5) +$37.37

QTY: 53B- Glass Clip Gasket [8 required per unit, each sold separately] (3120-021) +$10.65

QTY: 53C- Glass Retention Clip [8 required per unit, each sold separately] (5021-060) +$13.01

QTY: 56- Ash Grate Control Rod (5021-035) +$35.18

QTY: 57- Primary Air Control Retainer (5021-020) +$47.03

QTY: 58- Ash Pan (5021-010) +$112.39

QTY: 59- Optional Fan Kit (90-57210) +$348.60

QTY: 70- Optional Outside Air Kit (90-53210) +$75.60

QTY: 76- Optional Rear Heat Shield (90-68210) +$173.25

QTY: 78- Threaded Rod 3/8 INCH - 16 X 20-1/2 INCH (5210-2320) +$47.03

QTY: 79- Cover Plate (2010-282) +$107.31

QTY: 80- Air Control Bushing (5550-155) +$34.02

QTY: 81- Ash Grate Base (2010-227) +$164.35

QTY: 83- 5/16 INCH Washer (4600-0800) +$10.65

QTY: 84- Right Side Impact Plate (2010-422) +$157.99

QTY: 85- Ash Pan Control Handle (5021-037) +$51.03

QTY: 86- Side Door Latch Assembly [includes] (90-73213) +$108.58

QTY: 86a- Screw: Set (4500-2976) +$10.65

QTY: 86b- Spacer (4700-0790) +$10.65

QTY: 86c- Chrome Handle Crank (5010-081) +$47.03

QTY: 86d- Latch: Door, Single Bevel (5021-023) +$48.36

QTY: 86e- Washer: Flat (5021-032) +$10.65

QTY: 86f- Spring: Latch (5240-138) +$23.35

QTY: 87- Gasket Kit [Kit includes Gaskets for: front, side, ash pan door, glass, and gasket glue] (90-58210) +$84.44

Item Description (Part Number)

QTY: 89a- Front Door Support Replacement Kit Matte Black (90-85210-10) +$734.05

QTY: 89b- Front Door Support Replacement Kit Brown Enamel (90-85210-20) +$904.01

QTY: 89c- Front Door Support Replacement Kit Black Enamel (90-85210-50) +$904.01

QTY: 89d- Front Door Support Replacement Kit Blue-Black Enamel (90-85210-59) +$ 904.01

QTY: 89e- Front Door Support Replacement Kit Seafoam Enamel (90-85210-61) +$ 904.01

QTY: 89f- Front Door Support Replacement Kit Almond Enamel (90-85210-30) +$ 904.01

Item description (Part Number)

QTY: Ash Grate Base Bottom Cast Screw [2 required per unit, each sold separately] (4500-0570) +$10.65

QTY: Primary Air Control Handle to Bottom Cast Screw [Qty 1] (4500-0700) +$10.65

QTY: Primary Air Control Handle to Bottom Cast lock Washer [Qty 1] (4600-0400) +$10.65

QTY: Primary Air Control Handle to Bottom Cast Piviot Bushing [Qty 1] (5550-155) +$34.02

QTY: Bottom Cast Channel Gasket Rope Med Den [8 feet required, [Sold per foot] (3110-057) +$10.65

QTY: Ash Pan Door Gasket Rope Med Den [36in] (3110-059) +$10.65

QTY: Ash Pan to Bottom Casting Screw [6 required per unit, each sold separately] (4500-0920) +$10.65

QTY: Bottom Casting Screw [4 required per unit, each sold separately] (4500-3220) +$10.65

QTY: Feet to Bottom Casting Lock Washer [4 required per unit, each sold separately] (04600-0850) +$Call to order

QTY: Feet to Bottom Casting Flat Washer [4 required per unit, each sold separately] (4600-0800) +$10.65

QTY: Primary Air Control Slide Retainer Screw [2 required per unit, each sold separately] (4500-3436) +$10.65

QTY: Side Door Plate to Side Door Frame Screw [2 required per unit, each sold separately] (4500-3436) +$10.65

QTY: Inner to Outter Side Door Frame Screw [4 required per unit, each sold separately] (4500-0500) +$10.65

QTY: Baffle Support/Baffle to Secondary Manifold Cotter Pin [2 required per unit, each sold separately] (4300-0110) +$10.65

QTY: Front Door Frame to Stove Body Gasket tape [5.5ft] (3160-392) +$10.65

QTY: Front Door Frame to Primary Plenum Screw [4 required per unit, each sold separately] (4500-1359) +$10.65

QTY: Top Casting to Bottom Casting Rods [Qty 1] (5210-2320) +$47.03

QTY: Top Casting to Bottom Casting Rods Conical Nut [Qty 1] (4200-0410) +$13.01

QTY: Top Casting to Bottom Casting Rods Finishing Nut [Qty 1] (4200-0400) +$10.65

QTY: Outside Door Frame Top to Top Cast Screw [Qty 1] (4500-2855) +$10.65

QTY: Primary AirOutside Door Frame Top to Top Cast Nut [Qty 1] (4200-0410) +$13.01

QTY: Outside Door Frame Bottom to Bottom Cast Screw [Qty 1] (4200-2910) +$Call to order

QTY: Outside Door Frame Bottom to Bottom Cast Finishing Nut [Qty 1] (4200-0400) +$10.65

QTY: Outside Door Frame Bottom to Bottom Cast Lock Washer [Qty 1] (4600-0700) +$10.65

QTY: Side Rondel to Inner Strike Plate Screw [Qty 2] (4500-1420) +$17.01

QTY: Side Rondel to Inner Strike Plate Fininshing Nut [2 required per unit, each sold separately] (4200-0200) +$10.65

QTY: Side Rondel to Inner Strike Plate Flat Washer [2 required per unit, each sold separately] (4600-0300) +$10.65

QTY: Secondary Manifold to Rear Flue Plate Screw [Qty 1] (4500-1420) +$17.01

QTY: Secondary Manifold to Rear Flue Plate Washer [Qty 1] (4600-0300) +$10.65

QTY: Top Casting Stone Channel Gasket Rope [6.7 Ft required, Sold per foot] (3110-057) +$10.65

QTY: Rear Heat Shield to Top Cast Screw [4 required per unit, each sold separately] (4500-0570) +$10.65

QTY: Flue Collar Gasket Gasket Rope [3.2 ft] (3110-056) +$11.68

QTY: Flue Collar Stud [4 required per unit, each sold separately] (4500-1351) +$10.65

QTY: Flue Collar Stud Finishing Nut [4 required per unit, each sold separately] (4200-0250) +$10.65

QTY: Flue Collar Stud Washer [4 required per unit, each sold separately] (4600-300) +$Call to order

QTY: Front Door Glass Clip Screws [8 required per unit, each sold separately] (4500-1874) +$10.65

QTY: Front Door Hinge Pins Rivet [2 required per unit, each sold separately] (4400-0300) +$10.65

QTY: Front Door Hinge Pins Washer [2 required per unit, each sold separately] (4600-1210) +$10.65

QTY: Side Door Stone Retainer Screw [4 required per unit, each sold separately] (4500-1910) +$10.65

QTY: Side Door Hinge Pins Rivet [2 required per unit, each sold separately] (4400-0300) +$10.65

QTY: Side Door Hinge Pins Washer [2 required per unit, each sold separately] (4600-1210) +$10.65

QTY: Top to Bottom, Front Holes Screw [2 required per unit, each sold separately] (4500-0560) +$10.65

QTY: Top to Bottom, Rear Holes Screw [2 required per unit, each sold separately] (4500-1300) +$10.65

Item Description (Part Number)

QTY: SOAP STONE STEAMER W/ BLUE BLACK ENAMEL LID (90-99112) +$135.45

QTY: THERMOMETER-STOVETOP,SOAPSTONE (90-99120) +$27.30
