Tucson VF Model 8740 Parts


Item#: 8740

Price: $0.00


Order Now

Item description (Part Number)

QTY: 1 Top Stone Polished Gray (1741-350) +$66.79

QTY: 1a Black Orion Top Stone (1755-350) +$114.93

QTY: 2 Side Stone Polished Gray (1741-351) +$181.61

QTY: 3 Top Center Stone Polished Gray (1741-352) *No longer available* +$*0.00*

QTY: 4 Bottom Casting (2710-116) +$342.38

QTY: 5 Ashlip (2710-220) +$224.24

QTY: 6 Right Side Casting (2710-321) +$275.39

QTY: 7 Left Side Casting (2710-326) +$258.34

QTY: 8 Firebox Baffle - Cast (2710-482) +$Call to order

QTY: 9 Door (2710-511) +$309.50

QTY: 10 Glass Retainer Frame (2710-560) +$123.83

QTY: 11 Front Grill (2710-581) +$173.08

QTY: 12 Door Handle (2710-655) +$17.01

QTY: 13 Top Grill Plate (2710-810) *No longer available* +$*0.00*

QTY: 14 Top Casting (2710-818) +$358.22

QTY: 15 Catalyst - Stainless Steel (3010-157) +$595.73

QTY: 16 Glass with Gasket (97-58705) +$188.92

QTY: Glass 13 1/4 inch x 11-1/4 inch x 5 mm ~Old part #3030-027~ (97-58705) +$188.92

QTY: Gasket Tape 3/4 inch x 1/16 inch x 5 ft (3160-080) +$10.65

QTY: 17 [5'] 3/8 inch Gasket [Sold per foot] (3110-057) +$10.65

QTY: 18 Gasket Tape 3/4 inch x 1/16 inch x 5 ft (3160-080) +$10.65

QTY: 19 Label: On/Off/T-Stat (3300-334) +$31.35

QTY: 20 Lighting Instruction Label (3300-502) +$31.35

QTY: 21 Safety Rating Label (3300-508) +$Call to order

QTY: 22 Combustion/Vent Warning Label (3300-512) +$27.35

QTY: 23 Hinge Cap Plugs 3/16 inch ID x 11/16 inch OD (4700-0605) +$10.65

QTY: 24 Access Door Magnet (4700-0795) +$14.34

QTY: 25 Threaded Rod 1/4-20 x 19 inch (5210-3070) +$13.01

QTY: 26 Ember Support Screen (5320-070) +$47.87

QTY: 27 Bottom Light Screen (5710-119) +$45.33

QTY: 28 Valve & Ignitor Bracket (5710-121) +$168.21

QTY: 29 Access Door (5710-128) +$41.52

QTY: 30 ODS Pilot Bracket (5710-131) +$38.98

QTY: 31 Burner Tube Holder Serial (5710-152) +$65.52

QTY: 32 Air Intake Flap (5710-160) +$45.33

QTY: 33 Hinge Bracket (5710-170) +$Call to order

QTY: 34 Latch Bracket (5710-180) +$32.76

QTY: 35 Stone Clip (5710-470) +$45.33

QTY: 36 Firebox (5710-513) +$494.63

QTY: 37 Exhaust Baffle Plate (5710-515) +$45.33

QTY: 38 Catalyst Heat Shield ~No longer available~ (5710-530) +$*0.00*

QTY: 39 Rear Shroud (5710-597) +$Call to order

QTY: 40 On/Off/T-Stat Wire Harness (7000-032) +$59.17

QTY: 41 On/Off/T-Stat Switch (7000-200) +$64.25

QTY: 42 Main Burner Orifice #45 (7200-145) +$17.01

QTY: Main Burner Orifice #55 (7200-120) +$14.34

QTY: 43 Fitting 3/8 inch NPT x 3/8 inch Compression (7210-007) +$38.98

QTY: 44 Piezo Igniter ~Old Part #7210-103~ New Part # (90-99020) +$47.03

QTY: 45 Manifold supply Tube ~Old part #7211-005~ (7211-018) +$45.33

QTY: 46 Pilot Tube w/ fittings (7211-007) +$47.87

QTY: 47 90 degree elbow (7211-020) +$46.60

QTY: 48 Burner Tube (7211-227) +$173.08

QTY: 49 SIT Nova 820 Valve NG 33% Turn Down (7211-301) +$285.14

QTY: SIT Nova 820 Valve LP 33% Turn Down (7211-305) +$303.41

QTY: 50 ODS Pilot NG (7211-324) +$246.16

QTY: ODS Pilot LP (7211-327) +$199.88

QTY: 51 Piezo Wire (7211-421) +$27.35

QTY: 52 Log Set (97-57210) +$291.23

QTY: Rear Log (7211-554) +$159.26

QTY: Middle Log (7211-555) *No longer available* +$*0.00*

QTY: Front Log (7211-556) +$160.90

QTY: Top Log (7211-557) *No longer available* +$*0.00*

QTY: Ceramic Embers (7211-558) +$64.25

QTY: Ember Screen (5320-070) +$47.87

QTY: Pilot Shield (5710-141) +$40.25

Item Description (Part Number)

QTY: WALL THERMOSTAT WITH 40FT WIRE (90-56920) *No longer available* Sub part #s PSM30 and 7000-014 +$*0.00*

QTY: THERMOSTAT ONLY (PSM30) +$39.95

QTY: WIRE ONLY WITH TERMINALS (7000-014) +$89.52

Item description (Part Number)

QTY: Millivolt Wall Thermostat (7200-506) *No longer available* +$*0.00*
QTY:
