Heritage IV Wood Stove (8024) #8024

Heritage IV Wood Stove (8024)


Item#: 8024

Price: $0.00


Order Now

MAIN ASSEMBLY

Item Description (Part Number)

QTY: 1 STONE [2 per unit, each sold separately] (1-0000-101) +$91.70

QTY: 2 POLISHED FRONT TOP STONE [2 per unit, each sold separately] (1141-251) +$91.70

QTY: 3 POLISHED FRONT BOTTOM STONE [2 per unit, each sold separately] (1141-252) +$69.43

QTY: 4 POLISHED STONE [4 per unit, each sold separately] (1141-253) +$61.03

QTY: 5 POLISHED STONE [5 per unit, each sold separately] (1141-272) +$155.89

QTY: 6 POLISHED STONE [2 per unit, each sold separately] (1141-276) +$49.14

QTY: 7 POLISHED STONE [2 per unit, each sold separately] (1141-278) +$28.69

QTY: 8 POLISHED STONE [3 per unit, each sold separately] (1141-280) +$135.26

QTY: 9 POLISHED STONE - DRILLED FOR CATALYST [R] (1141-281) +$109.85

QTY: 10 POLISHED STONE [4 per unit, each sold separately] (1201-25) +$184.11

QTY: 11 POLISHED STONE (1201-26) +$184.11

QTY: 12 MATTE FOOT [4 per unit, each sold separately] (2010-205) +$61.03

QTY: 13 MATTE BOTTOM CASTING (2010-214) +$471.49

QTY: 14 ASH GRATE (2010-221) +$222.22

QTY: 15 SIDE LEG [4 per unit, each sold separately] (2010-231) +$210.84

QTY: 16 SIDE TRIM [MATTE] (2010-271) +$27.35

QTY: 17 SIDE IMPACT PLATE (2010-273) +$249.82

QTY: 18 REAR FLUE PLATE (2010-281) +$Call to Order

QTY: 19 FLUE BLANK PLATE (2010-282) +$117.47

QTY: 20 FLUE COLLAR (2010-285) +$206.94

QTY: 21 TOP CASTING (2010-291) +$388.67

QTY: 22 REAR BAFFLE BLANKET (3120-025) +$61.03

QTY: 23 SAFETY/RATING LABEL (3300-753) +$Call to Order

QTY: 24 PRIMARY AIR KNOB (3900-173) +$27.22

QTY: 25 CARRIAGE BOLT [4 per unit, each sold separately] (4100-0127) +$10.95

QTY: 26 SHOULDER SCREW (4100-0230) +$10.95

QTY: 27 PIPE LOCK NUT [2 per unit, each sold separately] (4200-0100) +$25.75

QTY: 28 FINISHING NUT [zinc] (4200-0200) +$10.95

QTY: 29 FINISHING NUT [stainless steel] (4500-0250) +$Call to Order

QTY: 30 NUT [2 per unit, each sold separately] (4200-0400) +$10.95

QTY: 31 TAMPER RESISTANT NUT [2 per unit, each sold separately] (4200-0410) +$14.34

QTY: 32 BLIND RIVET [2 per unit, each sold separately] (4400-0100) +$10.95

QTY: 33 CAP SCREW [4 per unit, each sold separately] (4500-0910) +$10.95

QTY: 34 SCREW (4500-1020) +$10.95

QTY: 35 CAP SCREW [2 per unit, each sold separately] (4500-1420) +$18.75

QTY: 36 CAP SCREW [4 per unit, each sold separately] (4500-3220) +$10.95

QTY: 37 T-CUT SCREW [18 per unit, each sold separately] (4500-3436) +$10.95

QTY: 38 FLAT WASHER (4600-0300) +$10.95

QTY: 39 FLAT WASHER [13 per unit, each sold separately] (4600-0310) +$10.95

QTY: 40 LOCK WASHER [2 per unit, each sold separately] (4600-0700) +$10.95

QTY: 41 FLAT WASHER [6 per unit, each sold separately] (4600-0800) +$10.95

QTY: 42 LOCK WASHER [4 per unit, each sold separately] (4600-0850) +$10.95

QTY: 43 WASHER [2 per unit, each sold separately] (4600-0880) +$10.95

QTY: 44 SPRING WASHER (4600-1415) +$32.69

QTY: 45 DOOR SPACER (4700-0850) +$11.40

QTY: 46 PRIMARY AIR SLIDE RETAINER (5021-020) +$47.87

QTY: 47 CENTER BOTTOM SHIELD (5022-010) +$108.58

QTY: 48 OUTSIDE AIR PLENUM (5022-012) +$229.11

QTY: 49 AIR CONTROL HANDLE (5024-020) +$80.49

QTY: 50 PRIMARY AIR CONTROL SLIDE (5024-025) +$33.89

QTY: 51 SECONDARY AIR RESTRICTOR (5024-041) +$Call to Order

QTY: 52 REAR BAFFLE SUPPORT (5031-105) +$68.03

QTY: 53 BYPASS ESCUTCHEON (5031-125) +$51.38

QTY: 54 PROBE ESCUTCHEON (5031-130) +$45.77

QTY: 55 LABEL CLIP (5100-010) +$Call to Order

QTY: 56 THREADED ROD [2 per unit, each sold separately] (5210-2330) +$28.69

QTY: 57 LABEL CABLE (5570-030) +$30.02

QTY: 58 CATALYST TEMPERATURE PROBE (7200-525) +$83.29

QTY: 59 DAM (5024-110) +$Call to Order

QTY: 60 BYPASS DOOR (5024-115) +$Call to Order

QTY: 61 CATALYST [2 per unit, each sold separately] (3050-010) +$357.34

QTY: 62 BYPASS SHAFT (5024-120) +$60.44

QTY: 63 CAST HANDLE CRANK [3 per unit, each sold separately] (2010-254) +$66.79

QTY: 64 WOOD HANDLE [3 per unit, each sold separately] (3900-179) +$32.76

QTY: 65 SECONDARY AIR PLENUM BOTTOM (2010-241) +$190.00

QTY: 66 SECONDARY AIR PLENUM TOP (2010-244) +$340.48

QTY: 67 REAR CERAMIC BAFFLE BOARD [includes rear and front baffle boards] ~Old Part # 3120-024~ (90-76240) +$147.72

QTY: 68 MACHINE SCREW [4 per unit, each sold separately] (4500-1010) +$10.95

QTY: 69 SECONDARY AIR PIPE #1 (5021-041) +$104.30

QTY: 70 SECONDARY AIR TUBE #2 (5024-042) +$Call to Order

QTY: 71 SECONDARY AIR TUBE #3 (5024-043) +$Call to Order

QTY: 72 SECONDARY RISER PIPE (5024-045) +$63.83

QTY: 73 GASKET KEEPER (5023-048) +$Call to Order

QTY: 74 T-CUT SCREW (4500-3435) +$10.95

QTY: 75 BAFFLE BRACKET (5022-014) +$78.09

QTY: 76 FRONT CERAMIC BAFFLE BOARD [includes rear and front baffle boards] ~Old Part # 3120-023~ (90-76240) +$147.22

QTY: 77 COTTER PIN [4 per unit, each sold separately] (4300-0110) +$10.95

QTY: 78 PRIMARY AIR PLENUM (2010-251) +$Call to Order

QTY: 79 FRONT DOOR FRAME (2010-264) +$Call to Order

QTY: 80 FRONT DOOR [MATTE] (2010-262) +$274.08

QTY: 81 GLASS KIT [includes: gasket, clips and screws] ~Old Part # 3030-038~ (90-58215) +$351.96

QTY: 82 GLASS CLIP GASKET [8 per unit, each sold separately] ~Old Part # 3120-021~ (3120-351) +$11.95

QTY: 83 MACHINE SCREW [8 per unit, each sold separately] (4500-2105) +$10.95

QTY: 84 GLASS CLIP [8 per unit, each sold separately] (5021-060) +$11.40

QTY: 85 HINGE PLATE [4 per unit, each sold separately] (5022-026) +$25.75

QTY: 86 HINGE BUSHING [2 per unit, each sold separately] (5030-045) +$27.35

QTY: 87 MACHINE SCREW [4 per unit, each sold separately] (4500-1359) +$11.40

QTY: 88 HINGE PIN [2 per unit, each sold separately] (5022-028) +$36.04

QTY: 89 MANIFOLD SUPPORT BRACKET [2 per unit, each sold separately] (5024-100) +$Call to Order

QTY: 90 DOUBLE BEVEL DOOR LATCH [2 per unit, each sold separately] (5021-026) +$90.29

QTY: 91 LATCH SPRING [2 per unit, each sold separately] (5240-138) +$27.22

QTY: 92 FLAT WASHER [2 per unit, each sold separately] (5021-032) +$10.95

QTY: 93 MACHINE SCREW [3 per unit, each sold separately] (4500-1680) +$15.81

QTY: 94 SCREW [14 per unit, each sold separately] (4500-0701) +$Call to Order

QTY: 95 SIDE DOOR FRAME (2010-234) +$184.04

QTY: 96 SIDE DOOR FRAME COVER (2010-236) +$390.91

QTY: 97 MATTE SIDE DOOR (2010-238) +$283.92

QTY: 98 SIDE DOOR STONE RETAINER (2010-239) +$274.08

QTY: 99 RIGHT HINGE SHAFT (5000-324) +$34.57

QTY: 100 LEFT HINGE SHAFT (5000-325) +$34.57

QTY: 101 SPRING RETAINING SLEEVE [2 per unit, each sold separately] (5000-106) +$44.37

QTY: 102 SIDE DOOR TORSION SPRING [2 per unit, each sold separately] (5240-142) +$105.70

QTY: 103 DOOR HINGE PLATE [2 per unit, each sold separately] (5000-320) +$44.37

QTY: 104 SIDE DOOR STOP PLATE (5022-018) +$139.32

QTY: 105 SHOULDER BUSHING [2 per unit, each sold separately] (5000-105) +$31.63

QTY: 106 SIDE DOOR HINGE CLIP [2 per unit, each sold separately] (5350-032) +$10.95

QTY: 107 CAP SCREW (4500-2810) +$10.95

QTY: 108 POLISHED STONE (1141-270) +$154.81

QTY: 109 LATCH STRIKER [left side] [2 per unit, each sold separately] (5030-060) +$54.18

QTY: 110 TAMPER RESISTANT NUT (4200-0415) +$32.69

QTY: 111 SCREW (4500-1035) +$10.95

QTY: 112 MACHINE SCREW [4 per unit, each sold separately] (4500-1300) +$10.95

QTY: 113 MACHINE SCREW [4 per unit, each sold separately] (4500-1910) +$10.95

QTY: 114 MACHINE SCREW [24 per unit, each sold separately] (4500-1876) +$10.95

QTY: 115 PIN [2 per unit, each sold separately] (4300-0195) +$10.95

QTY: 116 SET SCREW [4 per unit, each sold separately] (4500-2976) +$10.95

QTY: 117 DOOR LATCH SPACER [4 per unit, each sold separately] (4700-0790) +$10.95

QTY: 118 LOCK WASHER [22 per unit, each sold separately] (4600-0400) +$10.95

KITS AND ACCESSORIES

Item Description (Part Number)

QTY: 119 BLOWER (90-57210) +$439.00

QTY: 120 OUTSIDE AIR ADAPTER (90-53220) +$93.00

QTY: 121 REAR HEATSHIELD (90-68210) +$187.00

QTY: 122 CATALYST GASKET KIT (90-58313) +$44.37

QTY: 123 GLASS KIT [includes: gasket, clips and screws] (90-58215) +$351.96

QTY: 124 DOOR HANDLE KIT (90-71240) +$31.63

QTY: 125 DOOR LATCH KIT [includes: crank, screws, spacer, latch, washer and spring; no handle] (90-73240) +$90.29

QTY: 126 SIDE DOOR LOCK KIT (90-70210) +$40.00

QTY: 127 BAFFLE KIT [includes front and rear baffle boards] (90-76240) +$147.72

QTY: 128 CATALYST (90-75310) +$553.39

QTY: 129 GASKET KIT [includes: front, side, ash pan door, glass gaskets and gasket glue] (90-58230) +$79.09

QTY: 130 OWNERS MANUAL [hard copy] (OMHC-H) +$21.99

QTY: 131 OWNERS MANUAL [electronic copy] (OMEL-H) +$9.99

QTY: 132 SOAPSTONE STEAMER WITH BLUE BLACK ENAMEL LID (90-99112) +$199.00

QTY: 133 SOAPSTONE STOVETOP THERMOMETER (90-99120) +$30.00

QTY: 134 GLOVES (90-99031) +$61.00
QTY:
