CHAMPLAIN II GAS STOVE (8302) #8302

CHAMPLAIN II GAS STOVE (8302)


Item#: 8302

Price: $0.00


Order Now

MAIN ASSEMBLY

Item Description (Part Number)

QTY: 1 TOP - MATTE BLACK (2310-040) +$280.27

QTY: 2 SCREEN - TOP (5302-245) +$57.90

QTY: 3 HEAT EXCHANGER (2310-860) +$286.36

QTY: 4 GASKET [3 feet per unit, each foot sold separately] (3160-070) +$13.01

QTY: 5 SIDE - MATTE BLACK [2 per unit, each sold separately] (2310-340) +$721.18

QTY: 6 HEAT EXCHANGER BASE (2310-850) +$102.23

QTY: 7 LIMITER [4 per unit, each sold separately] (5302-118) +$27.35

QTY: 8 SIDE HEATSHIELD SPACER [4 per unit, each sold separately] (5323-032) +$Call to Order

QTY: 9 HEAT EXCHANGER GASKET (3160-150) +$18.34

QTY: 10 INNER SIDE HEATSHIELD [2 per unit, each sold separately] (5302-031) +$Call to Order

QTY: 11 TOP RIGHT GLASS CLIP (5300-106) +$42.79

QTY: 12 TOP SIDE BRACKET [2 per unit, each sold separately] (5302-235) +$27.35

QTY: 13 OUTER SIDE HEATSHIELD [2 per unit, each sold separately] (5300-030) +$76.82

QTY: 14 BOTTOM GLASS CLIP [3 per unit, each sold separately] (5300-102) +$32.69

QTY: 15 FIREBOX BAFFLE (2310-240) +$221.80

QTY: 16 REAR BRICK PANEL (2310-015) +$154.81

QTY: 17 PILOT SHIELD (5301-035) +$46.60

QTY: 18 BURNER (7211-221) +$377.71

QTY: 19 FRONT BRICK PANEL (2310-020) +$286.36

QTY: 20 GLASS CLIP [2 per unit, each sold separately] (5870-095) +$23.35

QTY: 21 GLASS - 14-7/32 INCHES X 18-35/64 INCHES X 5 MM (3030-036) +$458.09

QTY: 22 GLASS GASKET [6 feet per unit, each foot sold separately] (3110-071) +$14.34

QTY: 23 GLASS FRAME RETAINER CLIP [2 per unit, each sold separately] (5870-092) +$34.03

QTY: 24 GLASS RETAINTER (5300-108) +$271.74

QTY: 25 FRONT GLASS SAFETY SCREEN (5302-030) +$195.01

QTY: 27 FRONT - MATTE BLACK (2310-440) +$333.86

QTY: 28 FRONT CAST BRACKET [2 per unit, each sold separately] (5302-025) +$Call to Order

QTY: 29 DOOR ASH LIP - MATTE BLACK (2310-442) +$304.63

QTY: 30 ASH LIP BRACKET (5302-020) +$59.17

QTY: 31 PILOT GASKET (3160-152) +$18.34

QTY: 32 PILOT ASSEMBLY - NG [IPI, PSE] (7211-332) +$170.65

QTY: 33 VALVE SUPPORT CLIP (5323-015) +$15.68

QTY: 34 THERMOCOUPLE INTERRUPT - MAXITROL (7000-027) +$61.71

QTY: 35 VALVE - NG [MAXITROL] (7211-308) +$547.01

QTY: 36 WIRE - INTERRUPT [TC, MAX] (7000-029) +$44.06

QTY: 37 WIRE - INTERRUPT [SW, MAX] (7000-028) +$40.25

QTY: 38 WIRE HARNESS [MAX] (7000-044) +$40.25

QTY: 39 RCV BOARD [MAX] (7000-381) +$420.34

QTY: 40 CONTROL BOARD BRACKET (5323-030) +$41.52

QTY: 41 VALVE MOUNT BRACKET (5323-010) +$111.12

QTY: 42 BOTTOM HEATSHIELD (5323-020) +$64.25

QTY: 43 BLINDER STRIP (5302-018) +$18.34

QTY: 44 BASE (5302-015) +$Call to Order

QTY: 45 FIREBOX (5302-010) +$Call to Order

QTY: 47 RESTIRCTOR CLIP (5301-080) +$42.79

QTY: 48 RESTIRCTOR PLATE INDICATOR (5301-070) +$23.35

QTY: 49 RESTRICTOR PLATE (5301-060) +$159.68

QTY: 50 INLET GASKET (3160-157) +$49.14

QTY: 51 EXIT GASKET (3160-155) +$38.98

QTY: 52 INLET/EXIT COLLAR (5701-925H) +$291.23

QTY: 53 AIR CONTROL GASKET (3160-300) +$23.35

QTY: 54 REMOTE [MAXITROL] (7000-360) *No Longer Available* +$*0.00*

QTY: 55 TOP LEFT GLASS CLIP (5300-104) +$42.79

QTY: 56 GAS FLEX TUBE (7211-018) +$46.60

QTY: 57 90 DEGREE ELBOW FITTING (7211-020) +$47.87

QTY: 58 90 DEGREE ELBOW FITTING (7211-023) +$59.17

QTY: 59 PRIMARY AIR CONTROL (5301-030) +$236.42

QTY: 60 BURNER ORIFICE #51 (7200-351) +$17.01

QTY: 61 LEFT REAR HEATSHIELD (5302-040) +$Call to Order

QTY: 62 TSTAT SWITCH FOR BLOWER (7000-301) +$61.71

QTY: 63 TSTAT SWITCH STRAP (5870-022) +$42.79

QTY: 65 RIGHT REAR HEATSHIELD (5302-050) +$Call to Order

QTY: 66 GLASS CLIP [3 per unit, each sold separately] (5021-060) +$14.34

QTY: 67 CABLE LABEL (5570-030) +$30.02

QTY: 69 VALVE ORIFICE #160 - LP [MAXTROL] (7211-172) +$38.98

QTY: 70 TOP REAR LOG (7211-605) +$186.48

QTY: 71 BOTTOM LEFT LOG (7211-604) +$182.83

QTY: 72 FRONT TOP LOG (7211-606) +$113.66

QTY: 73 FRONT CENTER LOG (7211-603) +$130.18

QTY: 74 BOTTOM RIGHT LOG ~Old Part # 7211-601~ (7211-602) +$187.70

QTY: 75 REAR RIGHT LOG (7211-602) +$187.70

QTY: 76 STRAIN RELIEF (7200-114) +$10.65

QTY: 77 TSTAT SHIELD (5970-110) +$46.60

QTY: 78 RHEOSTAT BOX COVER (5950-761) +$147.50

QTY: 79 VARIABLE SPEED CONTROL MOTOR (7200-601) +$104.77

QTY: 80 RHEOSTAT BOX (5950-760) +$137.80

QTY: 81 FAN CONTROL KNOB (7200-602) +$32.69

QTY: 82 BLOWER DEFLECTOR (5930-210) +$Call to Order

QTY: 83 GROMMET [4 per unit, each sold separately] (7000-130) +$32.69

QTY: 84 BUSHING [4 per unit, each sold separately] (5491-090) +$23.35

QTY: 85 UPPER BLOWER HOUSING (5932-315) +$Call to Order

QTY: 86 BLOWER ASSEMBLY (7211-600) +$437.39

QTY: 87 LOWER BLOWER HOUSING (5930-205) +$Call to Order

QTY: 88 CONVERSION KIT - NG TO LP (93-56201) +$128.91

QTY: 89 LOG SET (93-66020) +$437.39

QTY: 90 BLOWER KIT (93-57020) +$469.00

QTY: 91 CONVERSION KIT - LP TO NG (93-56020) +$38.98
QTY:
