Santa Fe Direct Vent Gas Stove (8760)


Item#: 8760

Price: $0.00


Order Now

Item Description (Part Number)

QTY: 1A- Polished Gray Soapstone Set (9760-41) +$293.93

QTY: 1- Polished Side Stone (1741-351) +$192.57

QTY: 2- Top Center Stone (1741-352) *No Longer Available* [can sub a larger stone and cut it] +$*0.00*

QTY: 3- Polished Top Side Stone (1741-680) +$90.29

QTY: 4- Firebox Baffle [cast] (2310-240) +$266.02

QTY: 5- Heat Exchanger Base [cast] (2310-850) +$102.23

QTY: 6- Heat Exchanger [cast] (2310-860) +$286.36

QTY: 7- Bottom [cast] (2710-600) +$257.12

QTY: 8- Ash Lip [cast] (2710-610) +$286.36

QTY: 9- Left Side Panel [cast] (2710-620) +$292.45

QTY: 10- Right Side Panel [cast] (2710-625) +$292.45

QTY: 11- Door Frame [cast] (2710-630) +$275.39

QTY: 12- Glass Retainer Frame [cast] (2710-640) +$Call to Order

QTY: 13- Front Door [cast] (2710-650) +$257.12

QTY: 14- Door Handle [matte cast] (2710-655) +$18.75

QTY: 14A- Door Handle [brown cast] (2720-655) *No Longer Available* +$*0.00*

QTY: 15- Front Grille [matte black] (2710-660) +$184.04

QTY: 16- Top [matte black] (2710-670) +$473.93

QTY: 16A- Top [brown enamel] (2720-670) +$295.92

QTY: 17- Top Grille [matte black] (2710-810) *No Longer Available* +$*0.00*

QTY: 18- Glass with Gasket ~Old Part # 3030-028~ (97-58605) +$262.00

QTY: 19- Gasket Rope 3/8 inch [sold per foot] (3110-057) +$11.40

QTY: 20- Gasket Rope 5/8 inch [2 square feet] ~Old Part #3160-075~ (CFPAP1/8-48-65-2) +$21.30

QTY: 21- Gasket Tape 3/4 inch [sold per foot] (3160-080) +$11.40

QTY: 22- Inlet Gasket (3160-135) +$32.69

QTY: 23- Heat Exchanger Gasket (3160-150) +$25.75

QTY: 24- Pilot Assembly Gasket (3160-152) +$25.75

QTY: 25- Inlet Collar Gasket (3160-157) +$61.03

QTY: 26- On/Off/T-Stat Label (3300-334) +$36.12

QTY: 27- Lighting Instructions Label -Left (3300-524) +$31.35

QTY: 28- Lighting Instructions Label -Right (3300-525) +$18.34

QTY: 29- Installation Instructions Label (3300-526) +$Call to Order

QTY: 30- Safety/Rating Label (330-551) +$Call to Order

QTY: 31- Fuel Conversion Label (330-556) +$Call to Order

QTY: 32- Finishing Plug (4700-0600) +$11.40

QTY: 33- Valve Door Magnet (4700-0795) +$15.68

QTY: 34- Threaded Rod (5210-3070) +$14.34

QTY: 35- Firebox -serial# pre 002194 (5300-010) *No Longer Available* +$*0.00*

QTY: 35A- Firebox -serial# post 002194 (5300-011) *No Longer Available* +$*0.00*

QTY: 36- Left Rear Heatshield (5300-040) +$Call to Order

QTY: 37- Right Rear Heatshield (5300-050) *No Longer Available* +$*0.00*

QTY: 38- Air Intake (5300-060) +$171.86

QTY: 39- Piezo & On/Off Switch Bracket (5300-066) +$66.63

QTY: 40- Valve & Pilot Bracket (5300-080) +$154.81

QTY: 41- Pilot Shield (5300-085) +$38.98

QTY: 42- Secondary Air Plenum (5300-090) +$243.73

QTY: 43- Ember Support Screen (5300-095) +$62.98

QTY: 44- Baffle Chip (5300-110) +$Call to Order

QTY: 45- Restrictor Plate (5300-112) +$44.06

QTY: 46- Restrictor Plate Rod (5300-114) +$56.63

QTY: 47- Blast Limiter ~Old Part # 5300-118~ (5302-118) +$27.35

QTY: 48- Inlet/Exit Collar (5710-925H) +$Call to Order

QTY: 49- Stone Clip (5710-470) +$46.60

QTY: 50- Left Valve Door Bracket (5160-010) *No Longer Available* +$*0.00*

QTY: 51- Right Valve Door Bracket (5760-020) +$38.98

QTY: 52- Valve Door (5760-030) +$108.58

QTY: 53- Front Door Hinge Bracket (5760-040) +$Call to Order

QTY: 54- Restrictor Indicator Plate (5800-210) +$17.01

QTY: 55- On/Off Wire Harness (7000-031) +$62.98

QTY: 56- 3-Way On/Off/T-Stat Switch (7000-200) +$84.69

QTY: 57- Burner Orifice NG #31 (7200-231) +$18.75

QTY: 57A- Burner Hood Orifice LP #49 (7200-249) +$27.22

QTY: 58- Straight Compression Fitting (7210-007) +$41.52

QTY: 59- Thermopile Metal Wrapped (7210-090) +$137.92

QTY: 60- Piezo Igniter with Pal Nut [this igniter is the round Part you push to generate a spark] ~Old Part #7210-103~ (90-99020) +$55.58

QTY: 61- Pilot Tube (7211-009) +$51.38

QTY: 63- 90 Degree Compression Elbow (7211-020) +$55.58

QTY: 64- Primary Air Control Shutter (7211-231) +$85.71

QTY: 65- Burner Tube - No Shutter (7211-247) +$436.56

QTY: 65A- Burner Tube - with Shutter (7211-245) *No Longer Available* [can sub One 7211-247 & One 7211-231] +$*0.00*

QTY: 66- SIT Universal Gas Valve [LP or NG][To convert this valve flip the conversion pin] [50% Turn Down] (7211-320) +$436.56

QTY: 66A- SIT Regulator Valve 50% Turndown - LP (7211-313) +$121.11

QTY: 67- 3 Way Top-Convertible Pilot Assembly NG Sit [Includes: Thermopile, Thermocouple, Pilot, Pilot Tube, Electrode with wire] [recommend using High Temp Red Silicone] [To convert to LP you must also order Part #7211-136] (7211-370) +$307.65

QTY: 67a- Screw in Pilot Orifice - LP #30mm ~Old Part # 7211-131~ (7211-136) +$66.63

QTY: 68- 3-Way SIT Pilot Hood Top Convertible (7211-390) +$48.57

QTY: 69- On/Off Valve Extension Knob (7211-401) +$28.69

QTY: 70- Hi/Low Extension Knob (7211-402) +$28.69

QTY: 71- Ceramic Electrode with Piezo Wire (7211-430) +$45.77

QTY: 72- Thermocouple (7211-470) +$48.57

QTY: 73- Ceramic Embers (7211-558) +$93.10

QTY: 74A- Log Set (93-57210) +$349.69

QTY: 74- Rear Log (7211-530) +$151.16

QTY: 75- Middle Log (7211-531) +$162.12

QTY: 76- Front Log (7211-532) +$147.50

QTY: 77- Top Log (7211-533) +$111.12

QTY: 80- Hard Wired Wall Thermostat [wire sold separately 7000-014] (90-56920) +$48.74

QTY: 81- Thermostat Wire with Terminals [40 ft](7000-014) +$109.90

QTY: 82- Hard Wired Wall Thermostat [wire sold separately 7000-014] ~Old Part # 7200-506~ (90-56920) +$48.74

QTY: 83- NG Conversion Kit 50% Turn Down, Top Convertible, Includes 3 items below (97-56600) +$157.25

QTY: 84- #31 NG Burner Orifice (7200-231) +$18.75

QTY: 85- SIT Pilot Orifice .62mm NG with Threads (7211-163) +$68.03

QTY: 86- SIT Regulator Valve 50% Turndown - NG (7211-312) +$153.33

QTY: 87- LP Conversion Kit 50% Turn Down, Top Convertible, Includes 3 items below (97-56601) +$130.18

QTY: 88- #49 LP Burner Orifice (7200-249) +$27.22

QTY: 89- .30mm LP Pilot Orifice with threads ~Old Part # 7211-131~ (7211-136) +$66.63

QTY: 90- SIT Regulator Valve 50% Turndown - LP (7211-313) +$121.11

QTY: 91- Vent Restrictor [serial# pre 002194] Includes 3 items below (93-65010) +$65.52

QTY: 92- Exit Gasket (3160-155) +$45.77

QTY: 93- Restrictor Plate (5950-916) +$Call to Order

QTY: 94- Soapstone Steamer with Blue Black Enamel Lid (90-99112) +$199.00

QTY: 95- Owners Manual [hard copy] (OMHC-H) +$21.99

QTY: 96- Owners Manual [electronic copy] (OMEL-H) +$9.99
